ASUS MAXIMUS IX CODE, DDR4, SATA3, USB3.1, DP, AC WiFi, LGA1151 ATX - MAXIMUS IX CODE

PODNOŽJE: INTEL LGA 1151
ZA PROCESORJE: 7th/6th Generation Core™
FORMAT: ATX Form Factor 30.5 x 24.4cm
VEZNI ČIP: Intel Z270
POMNILNIK:
4 x DIMM DDR4 (4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3333(O.C.)/3300(O.C.)/3200(O.C.)/3000(O.C.)/2800(O.C.)/2666(O.C.)/2400(O.C.)/2133(O.C.)MHz) do skupno 64GB kapacitete, dual channel podpora
GRAFIKA: DA / preko CPU
RAID: DA (0,1,5,10)
RAZŠIRITVENE REŽE:
2 x PCIe 3.0/2.0 x16
1 x PCIe 3.0/2.0 x4
3 x PCIe 3.0/2.0 x1
MREŽNA KARTICA: Intel® I219V, 1 x Gigabit LAN Controller(s)
ZVOČNA KARTICA: SupremeFX 8-Channel High Definition Audio CODEC
NOTRANJI PRIKLJUČKI: 2 x Aura RGB Strip Headers 1 x USB 3.0 connector(s) support(s) additional 2 USB 3.0 port(s) 1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s) 1 x M.2 Socket 3 with M Key, type 2242/2260/2280/22110 storage devices support (SATA mode & X4 PCIE mode) 1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (PCIE mode only) 1 x TPM connector(s) 6 x SATA 6Gb/s connector(s) 1 x CPU Fan connector(s) (1 x 4 -pin) 1 x CPU OPT Fan connector(s) (1 x 4 -pin) 3 x Chassis Fan connector(s) (3 x 4 -pin) 1 x H_AMP fan connector 1 x W_PUMP+ connector (1 x 4 -pin) 1 x AIO_PUMP connector (1 x 4 -pin) 1 x 24-pin EATX Power connector(s) 1 x 8-pin ATX 12V Power connector(s) 1 x Front panel audio connector(s) (AAFP) 1 x System panel(s) (Q-Connector) 1 x MemOK! button(s) 1 x Slow Mode switch(es) 1 x Reset button(s) 1 x LN2 Mode jumper(s) 1 x ROG extension (ROG_EXT) header(s) 1 x Safe Boot button 1 x ReTry button 1 x EXT_Fan header 1 x W_IN header 1 x W_OUT header 1 x W_FLOW header 1 x Thermal sensor connector 1 x Start button 1 x USB 3.1 front panel connector ZUNANJI PRIKLJUČKI:
1 x DisplayPort
1 x HDMI
1 x LAN (RJ45) port(s)
1 x USB 3.1 (black)Type-A
1 x USB 3.1 (red)Type-C
4 x USB 3.0 (blue)
4 x USB 2.0
1 x Optical S/PDIF out
5 x Audio jack(s)
1 x Clear CMOS button(s)
2 x Wi-Fi antenna port(s)
1 x USB BIOS Flashback Button(s)
DODATNO: Clear CMOS button
ROG Armor
ROG RAMCache II
ROG CloneDrive
MemOK! Button
ReTry Button
Safe Boot Button
Start Button
Reset Button
LN2 Mode
GameFirst IV
ROG Aura
Aura Lighting Control
Aura RGB Strip Headers
Extreme Engine Digi+ :
MicroFine Alloy Chokes
NexFET™ Power Block MOSFET
10K Black Metallic Capacitors
KeyBot II
X.M.P.
ClrCMOS
Power On
UEFI BIOS features :
O.C. Profile
Tweakers' Paradise
ROG SSD Secure Erase
Graphic Card Information Preview
ROG RAMDisk
Extreme Tweaker
BIOS Flashback
Special Features
ASUS Dual Intelligent Processors 5-Way Optimization by Dual Intelligent Processors 5 :
5-Way Optimization tuning key perfectly consolidates TPU, EPU, DIGI+ VRM, Fan Expert 4, and Turbo App
ASUS Exclusive Features :
MemOK!
AI Suite 3
Ai Charger
ASUS EZ DIY :
ASUS CrashFree BIOS 3
ASUS EZ Flash 3
ASUS USB BIOS Flashback
ASUS Q-Design :
ASUS Q-Shield
ASUS Q-Code
ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
ASUS Q-Slot
ASUS Q-DIMM
ASUS Q-Connector
Overclocking Protection :
ASUS C.P.R.(CPU Parameter Recall)
